General Information & Features
NARROW PROJECTION: projects just 2 1/8″ from the door.
NON-HANDED: installs on either left or right hand doors.
ADJUSTABLE SPRING POWER: 50% power adjustment.
ADJUSTABLE SWEEP AND LATCH SPEEDS: separate valves to adjust each speed.
ADJUSTABLE BACKCHECK STANDARD
STANDARD COVER: molded high impact UL listed plastic, non handed.
OPTIONAL COVER: Steel material with architectural finishes (8500 Series only). Suffix M, “8504M”. This cover is handed for top jamb closers.
STANDARD PACKAGE MOUNTS REGULAR OR TOP JAMB: for parallel prefix “P” to closer series number. Example: P8502.
HOLD-OPEN ARM: available with 90 to 180 Hold-Open. Suffix “H” to catalog number. Example: 8304H.
ADJUSTABLE DELAYED ACTION CLOSING OPTION: closers will be furnished with backcheck. Suffix “DA” to catalog number. Example: 8504DA.
ANSI A156.4 GRADE 1; UL LISTED; 10-YEAR WARRANTY; MADE IN USA.
PARALLEL RIGID ARM: available with one piece secondary arm. Prefix “PR” to catalog number. Example: PR8103.
CloserPLus ARM “CLP” OPTION
UNITROL ARM “UNI”/”UNI-J” OPTION
SLIDE TRACK OPTION
OPTIONAL ARMS: Parallel Rigid, CloserPLus, Unitrol.
