General Information & Features
NARROW PROJECTION: Projects just 1 15/16″ without cover, 2 1/16″ with cover
NON-HANDED: can be installed on either left or right hand doors.
ADJUSTABLE SWEEP AND LATCH SPEEDS: Separate valves to adjust each speed.
ADJUSTABLE BACKCHECK-OPTIONAL: Suffix “BC” to the catalog number.
NO COVER STANDARD
OPTIONAL COVER: Molded full cover, high impact UL listed plastic (1703XCOV or 1703BCXCOV). Secure snap on fit, no fasteners.
TRI-STYLE INSTALLATION: installs regular arm, parallel arm or top jamb from standard carton.
HOLD-OPEN ARMS AVAILABLE: Available with 90 to 180 hold open – Suffix “H” (1703BC-H)
ANSI 156.4 GRADE 2; UL LISTED; MADE IN USA.
